輸入軸轉(zhuǎn)速 Input shaft speed (min) |
1480 | 柱塞行程 Plunger stroke (mm) |
66 | |||||
齒輪減速比 gear reduction ratio i |
2.761 | 泵速 pump speed(min-1) |
525 | |||||
電機(jī)功率 motor power(KW) |
30 | 37 | 45 | 55 | 75 | 柱塞直徑 diameter of plunger (mm) | ||
公稱流量 Nominal flow |
額定壓力 rated pressure (Mpa) | |||||||
M3/h | L/min | |||||||
1.8 | 30 | 45 | -- | -- | -- | -- | 20 | |
2.4 | 40 | 35 | 45 | -- | -- | -- | 22 | |
3 | 50 | 30 | 40 | 45 | -- | -- | 25 | |
3.6 | 60 | 25 | 30 | 40 | 45 | -- | 26 | |
4.2 | 70 | 20 | 25 | 30 | 40 | 50 | 28 | |
4.8 | 80 | 18 | 22 | 28 | 35 | 45 | 32 | |
5.4 | 90 | 15 | 20 | 25 | 30 | 40 | 33 | |
6.3 | 100 | 12 | 15 | 20 | 25 | 35 | 35 |
